液壓夾緊，夾緊油缸缸徑為Ф100

Hydraulic clamping, clamping oil cylinder diameter is Ф100

液壓進刀，油缸缸徑為Ф63，液壓調速

Hydraulic feeding, oil cylinder diameter is Ф63, hydraulic speed regulation

電動切割，切割電機的功率為3KW

Electric cutting, cutting motor power is 3KW

液壓泵為上海高壓泵廠產品，額定壓力21Mpa,電機功率5.5KW

Hydraulic pump is a product of Shanghai High Pressure Pump Factory, with a rated pressure of 21Mpa and a motor power of 5.5KW

?

氣缸使鋸床隨動并返程，氣缸直徑Ф40×500

Cylinder makes the saw bed follow and return, cylinder diameter Ф40×500

陽極棒可調節的長度范圍為300～1000㎜

The length range of the anode rod that can be adjusted is 300~1000mm

?

配備前后滾輪架及出料校直滾輪組

Equipped with front and rear roller frame and discharge straightening roller group

?

配備電箱及液壓站

Equipped with electrical box and hydraulic station

?

配備鋸屑收集箱

Equipped with sawdust collection box

?

此機的中心高與精準公司350T擠壓機配套使用

The center height of this machine is matched with the 350T extruder of Precision Company.
